Megaflash LED
A Modern LED Replacement for PF300 Flashbulbs
A drop-in PF300 alternative engineered for stability, directional output, and thousands of cycles with zero degradation.
Overview
Unmatched Performance
Brighter. More reliable. Infinitely reusable. The LED evolution of high-speed flash.
Brighter
425,000 lumens from a compact DC power supply
Easy Setup
LEDs allow for test flashes to check your setup without replacing bulbs
Rugged Construction
Machined aluminum housing withstands shock waves and impact
Consistent Performace
Electronic triggering delivers <10 microsecond timing precision
Pulse Flash Technology
Intense illumination without heat buildup or bulky power requirements
Ballistic Window
Field-replaceable front window for rapid recovery after energetic testing
Data
Output Stability That PF300 Bulbs Can’t Match
MegaFlash LED maintains a near-flat output profile across a 20 ms flash period, significantly improving accuracy for high-speed imaging and measurement tasks compared to PF300 bulbs.
RGB Pixel Values: PF300 vs MegaFlash LED
Specifications
MegaFlash LED
The MegaFlash LED delivers superior performance across critical metrics. Our advanced engineering ensures maximum efficiency and reliability in every flash.
| Specifications | Mega Flash LED |
|---|---|
| Flash Duration | 1-50 ms (factory set) |
| Flash Brightness | 425, 000 lumens / 25° full angle |
| Inputs Power | 15 VDC/3A; Battery optional |
| Trigger Signal | TTL; BNC connector |
| Weight | 8.6 lbs (3.9 kg) |
| Dimensions | 8.9 x 7.0 x 4.8 inches |
| Cycle Degradation - 1000 flashes | None measurable |
| Enviromental | IP66/-40 to 65 °C |
| Output FoV | 25° degrees full angle |
Why Labs Switch
MegaFlash LED Key Differentiators
What makes MegaFlash LED the superior choice for demanding applications
Pulse Operation
50-millisecond pulse duration captures complete event sequences in a single flash. Sync multiple units for extended illumination
Directional Lighting
Engineered optics maximize on-target brightness. Optional tight-focus configurations available for extended standoff distances
LED Technology
Solid-state LEDs deliver superior efficiency, faster response, and longer lifespan than traditional flash bulbs
Reusability
Built for continuous use with zero consumables—consistent high-performance with no waste
APPLICATIONS
Versatile Performance Across Industries
Energetics Test Labs
Scientific Research
Defense & Military Testing
High Speed Imaging
UPGRADe
Ready to Elevate Your Capabilities?
Discover how the MegaFlash LED can transform your high-precision imaging and testing capabilities.
